| Model |
IPC-D149H |
| Image Sensor |
1/2.8″ Progressive Scan CMOS |
| Max. Resolution |
2560 × 1440 |
| Min. Illumination |
Color: 0.001 Lux @ (F1.0, AGC ON), 0 Lux with light |
| Shutter Time |
1/3 s to 1/100,000 s |
| Day & Night |
24/7 color imaging |
| Angle Adjustment |
Pan: 0° to 355°, Tilt: 0° to 75°, Rotate: 0° to 355° |
| Lens Type |
Fixed focal lens, 2.8 mm and 4 mm optional |
| Focal Length & FOV |
2.8 mm: H 96°, V 52°, D 113° 4 mm: H 76°, V 41°, D 89° |
| Lens Mount |
M12 |
| Iris Type |
Fixed |
| Aperture |
F1.0 |
| Depth of Field |
2.8 mm: 2 m – ∞ 4 mm: 2.7 m – ∞ |
| DORI |
2.8 mm: D: 64 m, O: 25 m, R: 13 m, I: 6 m 4 mm: D: 77 m, O: 30 m, R: 15 m, I: 7 m |
| Supplement Light Type |
White Light |
| Supplement Light Range |
Up to 30 m |
| Smart Supplement Light |
Yes |
| Main Stream |
50 Hz: 20 fps (2560 × 1440), 25 fps (1920 × 1080, 1280 × 720) 60 Hz: 20 fps (2560 × 1440), 30 fps (1920 × 1080, 1280 × 720) |
| Sub Stream |
50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360) 60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360) |
| Video Compression |
Main stream: H.265+/H.265/H.264+/H.264 Sub-stream: H.265/H.264/MJPEG |
| Video Bit Rate |
32 Kbps to 8 Mbps |
| H.264 Type |
Baseline Profile, Main Profile, High Profile |
| H.265 Type |
Main Profile |
| Bit Rate Control |
CBR, VBR |
| Region of Interest (ROI) |
1 fixed region(s) for main stream |
| Security |
Password protection, complicated password, HTTPS encryption, watermark, IP address filter, authentication for HTTP/HTTPS, RTP/RTSP over HTTPS, TLS 1.2, security audit log, host authentication (MAC addre |
