| Model |
IPC-B150H |
| Image Sensor |
1/2.7″ Progressive Scan CMOS |
| Max. Resolution |
2560 × 1920 |
| Min. Illumination |
Color: 0.01 Lux @(F2.0, AGC ON), B/W: 0 Lux with IR |
| Shutter Speed |
1/3 s to 1/100,000 s |
| Day & Night |
IR cut filter |
| Angle Adjustment |
Pan: 0°–360°, Tilt: 0°–180°, Rotate: 0°–360° |
| Lens Type |
Fixed focal lens (2.8 mm & 4 mm optional) |
| Focal Length & FOV |
2.8 mm: H 98.0°, V 71.7°, D 127.0° 4 mm: H 75.3°, V 55.5°, D 98.2° |
| Lens Mount |
M12 |
| Iris Type |
Fixed |
| Aperture |
F2.0 |
| Supplement Light Type |
IR |
| Supplement Light Range |
Up to 30 m |
| IR Wavelength |
850 nm |
| Main Stream |
50 Hz: 20 fps (2560 × 1920) 25 fps (2560 × 1440, 1920 × 1080, 1280 × 720) 60 Hz: 20 fps (2560 × 1920) 30 fps (2560 × 1440, 1920 × 1080, 1280 × 720) |
| Sub Stream |
50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360) 60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360) |
| Video Compression |
Main stream: H.265+/H.265/H.264+/H.264 Sub stream: H.265/H.264/MJPEG |
| Video Bit Rate |
32 Kbps to 16 Mbps |
| H.264 Type |
Baseline Profile/Main Profile/High Profile |
| H.265 Type |
Main Profile |
| ROI |
1 fixed region for main stream |
| Protocols |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP™, SMTP, IGMP, QoS, IPv6, Bonjour, IPv4, UDP, SSL/TLS |
| Simultaneous Live View |
Up to 6 channels |
| API |
ONVIF, ISAPI |
| Users/Hosts |
Up to 32 users (Administrator/Operator/User) |
| Client |
iVMS-4200, Hik-Connect |
| Web Browser |
Plug-in required: IE 10+ Plug-in free: Chrome 57.0+, Firefox 52.0+ |
| Image Settings |
Saturation, Brightness, Contrast, Sharpness, AGC, White Balance |
| Day/Night Switch |
Auto, Schedule, Day, Night |
| WDR |
120 dB |
| Image Enhancement |
BLC, 3D DNR |
| Ethernet Interface |
1 × RJ45 10M/100M self-adaptive |
| Basic Event |
Motion detection, video tampering alarm, exception |
| Linkage Methods |
Upload to FTP, notify surveillance center, send email |
| Power Supply |
12 VDC ± 25%, 0.4 A, max. 5 W PoE: 802.3af, Class 3, 36–57 V, 0.2–0.15 A, max. 6.5 W |
| Dimensions |
186.3 × 71.4 × 66.7 mm |
| Package Dimensions |
216 × 121 × 118 mm |
| Weight |
270 g (net), 481 g (with package) |
| Operating Conditions |
-30 °C to 60 °C, Humidity ≤95% (non-condensing) |
| Storage Conditions |
-30 °C to 60 °C, Humidity ≤95% (non-condensing) |
| Languages |
English, Ukrainian |
| General Functions |
Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP filter |
| Certifications (EMC) |
FCC, CE-EMC, RCM, IC, KC |
| Safety |
UL, CB, CE-LVD, BIS |
| Environment |
CE-RoHS, WEEE, Reach |
| Protection |
IP67 |
