| Image Sensor |
1/2.9″ Progressive Scan CMOS |
| Max. Resolution |
1920 × 1080 |
| Min. Illumination |
Color: 0.01 Lux @ (F2.2, AGC ON), B/W: 0 Lux with IR |
| Shutter Time |
1/3 s to 1/100,000 s |
| Day & Night |
IR cut filter |
| Angle Adjustment |
Pan: 0°–360°, Tilt: 0°–90°, Rotate: 0°–360° |
| Lens Type |
Fixed focal lens, 2.8 mm & 4 mm optional |
| Focal Length & FOV |
2.8 mm: H 94°, V 51°, D 112°4 mm: H 80°, V 44°, D 94° |
| Lens Mount |
M12 |
| Iris Type |
Fixed |
| Aperture |
F2.2 |
| DORI |
2.8 mm: D 48 m, O 19 m, R 9 m, I 4 m4 mm: D 55 m, O 22 m, R 11 m, I 5 m |
| Supplement Light Type |
IR |
| Supplement Light Range |
Up to 20 m |
| Smart Supplement Light |
Yes |
| IR Wavelength |
850 nm |
| Main Stream |
50 Hz: 25 fps (1920×1080, 1280×720)60 Hz: 30 fps (1920×1080, 1280×720) |
| Sub-Stream |
50 Hz: 25 fps (640×480, 640×360)60 Hz: 30 fps (640×480, 640×360) |
| Video Compression |
Main: H.265+/H.265/H.264+/H.264Sub: H.265/H.264 |
| Video Bit Rate |
32 Kbps to 8 Mbps |
| H.264 Type |
Baseline Profile / Main Profile / High Profile |
| H.265 Type |
Main Profile |
| Bit Rate Control |
CBR / VBR |
| Audio Type |
Mono sound |
| Noise Filtering |
Yes |
| Sampling Rate |
8 kHz / 16 kHz |
| Audio Compression |
G.711ulaw / AAC-LC |
| Audio Bit Rate |
64 Kbps (G.711ulaw), 16–64 Kbps (AAC-LC) |
| Network Security |
Password protection, watermark, HTTP authentication, audit log, MAC address binding |
| Simultaneous Live View |
Up to 6 channels |
| API |
ISAPI, SDK |
| Protocols |
TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, UDP, QoS |
| Users/Hosts |
Up to 32 (Admin / Operator / User) |
| Client |
iVMS-4200 |
| Web Browser |
IE10/11 (plug-in), Chrome 57+, Firefox 52+ |
| WDR |
Digital WDR |
| SNR |
≥ 52 dB |
| Day/Night Switch |
Day / Night / Auto / Schedule |
| Image Enhancement |
BLC, HLC, 3D DNR |
| Image Settings |
Saturation, Brightness, Contrast, Sharpness, Gain, White Balance |
| Ethernet |
1 RJ45 10/100M self-adaptive |
| Built-in Microphone |
Yes |
| Events |
Motion detection (human), Exception |
| Event Linkage |
Notify surveillance center |
| Power |
12 VDC ±25%, 0.41 A, Max. 5 WPoE: IEEE 802.3af, Class 3, Max. 6.5 W |
| Material |
Plastic |
| Dimension |
138.8 × 60.9 × 57.9 mm (5.46″ × 2.4″ × 2.3″) |
| Package Dimension |
163 × 75 × 75 mm (6.4″ × 3.0″ × 3.0″) |
| Weight |
175 g (net), 250 g (with package) |
| Storage Conditions |
-30 °C to 60 °C, Humidity ≤ 95% (non-condensing) |
| Startup & Operating Conditions |
-30 °C to 60 °C, Humidity ≤ 95% (non-condensing) |
| Languages |
English, Ukrainian |
| General Functions |
Heartbeat, Anti-banding, Mirror, Password reset via email |
| Approvals – EMC |
FCC Part 15, CE-EMC, EN 55032, EN 61000 |
| Approvals – Safety |
CB: IEC 62368-1, CE-LVD: EN 62368-1 |
| Environment |
CE-RoHS, WEEE, REACH |
| Protection |
IP67 |
