| Image Sensor |
1/2.9″ Progressive Scan CMOS |
| Max. Resolution |
1920 × 1080 |
| Min. Illumination |
Color: 0.01 Lux @ (F2.2, AGC ON), B/W: 0 Lux with IR |
| Shutter Time |
1/3 s to 1/100,000 s |
| Day & Night |
IR cut filter |
| Angle Adjustment |
Pan: 0° to 360°, Tilt: 0° to 90°, Rotate: 0° to 360° |
| Lens Type |
Fixed focal lens, 2.8 mm and 4 mm optional |
| Focal Length & FOV |
2.8 mm: H 101°, V 56°, D 118° 4 mm: H 80°, V 44°, D 94° |
| Lens Mount |
M12 |
| Iris Type |
Fixed |
| Aperture |
F2.2 |
| DORI |
2.8 mm: D 44 m, O 17 m, R 8 m, I 4 m 4 mm: D 55 m, O 22 m, R 11 m, I 5 m |
| Supplement Light Type |
IR, White Light |
| Supplement Light Range |
IR: up to 20 m White Light: up to 15 m |
| Smart Supplement Light |
Yes |
| IR Wavelength |
850 nm |
| Main Stream |
50 Hz: 25 fps (1920 × 1080, 1280 × 720) 60 Hz: 30 fps (1920 × 1080, 1280 × 720) |
| Sub Stream |
50 Hz: 25 fps (640 × 480, 640 × 360) 60 Hz: 30 fps (640 × 480, 640 × 360) |
| Video Compression |
Main stream: H.265+/H.265/H.264+/H.264 Sub-stream: H.265/H.264/MJPEG |
| Video Bit Rate |
32 Kbps to 8 Mbps |
| H.264 Type |
Baseline Profile, Main Profile, High Profile |
| H.265 Type |
Main Profile |
| Bit Rate Control |
CBR, VBR |
| Region of Interest (ROI) |
1 fixed region for main stream |
| Audio Type |
Mono sound |
| Audio Sampling Rate |
8 kHz / 16 kHz |
| Environment Noise Filtering |
Yes |
| Audio Compression |
G.711ulaw / AAC-LC |
| Audio Bit Rate |
64 Kbps (G.711ulaw) / 16–64 Kbps (AAC-LC) |
| Protocols |
TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTCP, RTSP, NTP, IGMP, IPv4, IPv6, UDP, QoS |
| API |
ONVIF (Profile S, Profile T), ISAPI, SDK |
| Security |
Password protection, complicated password, watermark, HTTP auth, WSSE, audit log, host authentication (MAC) |
| Simultaneous Live View |
Up to 6 channels |
| User/Host |
Up to 32 users (Admin / Operator / User) |
| Client |
iVMS-4200, HiLookVision |
| Web Browser |
IE10, IE11 (Plug-in) Chrome 57+, Firefox 52+, Edge 89+ |
| Image Settings |
Saturation, brightness, contrast, sharpness, gain, white balance |
| WDR |
Digital WDR |
| SNR |
≥ 52 dB |
| Privacy Mask |
1 programmable polygon mask |
| Day/Night Switch |
Day, Night, Auto, Schedule |
| Image Enhancement |
BLC, HLC, 3D DNR |
| Ethernet Interface |
1 RJ45 10M/100M self-adaptive |
| On-Board Storage |
N/A |
| Built-in Microphone |
Yes (1 MIC) |
| Reset Key |
N/A |
| Event |
Motion detection (human target), exception |
| Event Linkage |
Notify center, email, recording, snapshot |
| Power |
12 VDC ±25% (0.42 A, max. 5 W) PoE: IEEE 802.3af, Class 3 (max. 6.5 W) |
| Material |
Plastic |
| Dimension |
138.8 × 60.9 × 57.9 mm (5.5″ × 2.4″ × 2.3″) |
| Package Dimension |
163 × 75 × 75 mm (6.4″ × 3.0″ × 3.0″) |
| Weight |
175 g (0.4 lb) With package: 250 g (0.55 lb) |
| Storage Conditions |
-30 °C to 45 °C, Humidity ≤ 95% (non-condensing) |
| Operating Conditions |
-30 °C to 45 °C, Humidity ≤ 95% (non-condensing) |
| Language |
English, Ukrainian |
| General Function |
Heartbeat, anti-banding, mirror, password protection, reset via email |
| Approval – EMC |
FCC Part 15, CE-EMC (EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021) |
| Approval – Safety |
CB: IEC 62368-1:2014+A11 CE-LVD: EN 62368-1:2014/A11:2017 |
| Approval – Environment |
CE-RoHS: 2011/65/EU WEEE: 2012/19/EU REACH: Regulation (EC) No 1907/2006 |
| Protection |
IP67 (IEC 60529-2013) |
