Camera

Image Sensor

1/3.2″ CMOS

Effective Pixels

1920(H) x1080(V)

RAM/ROM

64MB/16MB

Scanning System

Progressive

Electronic Shutter Speed

Auto/Manual, 1/3~1/100000s

Minimum Illumination

0.01 lux@F2.0 (Color, 30 IRE)

0.001 lux@F2.0 (B/W,30 IRE)

0 lux (Illuminator on)

S/N Ratio

>56 dB

IR Distance

Up to 30 m (98.43 ft) (IR LED)

IR On/Off Control

Auto/ Manual

IR LEDs

Angle Adjustment

2

Pan: 0°–360°

Tilt: 0°–90°

Rotation: 0°–360°

Lens

Lens Type

Fixed

Mount Type

M12

Focal Length

3.6 mm

Max. Aperture

F2.0

Angle of View

H: 79°; V: 43°; D: 94°

Focus Control

Fixed

Close Focus Distance

0.8 m (2.62 ft)

DORI Distance

Lens

Detect

Observe

Recognize

Identify

3.6 mm

55.0 m (180.45 ft)

22.0 m (72.18 ft)

11.0 m (36.09 ft)

5.5 m (18.04 ft)

Video

Compression

Smart Codec

H.265; H.264; H.264B; MJPEG (Only supported by the sub stream)

Smart H.265+; Smart H.264+

Streaming Capability

2 Streams

Resolution

1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); CIF (352 × 288/352 × 240)

Frame Rate

Main stream: 1920 × 1080@ (1–25/30 fps)

Sub stream: 704 × 576@ (1–25 fps)/704 × 480@ (1–30 fps)

*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.

Bit Rate Control

CBR/VBR

Bit Rate

H.265: 12Kbps ~ 4096Kbps

H.264: 32Kbps ~ 4096Kbps

Day/Night

Auto (ICR) / Color / B/W

BLC Mode

BLC / HLC /DWDR

White Balance

Auto; natural; street lamp; outdoor; manual; regional custom

Gain Control

Auto

Noise Reduction

3D DNR

Motion Detection

Off / On (4 areas, Rectangle)

Region of Interest

Off / On (4 areas)

Smart Illumination

Yes

Image Rotation

0°/180°

Mirror

Yes

Privacy Masking

Audio

Built-in MIC

Audio Compression

Alarm

Alarm Event

4 Areas

Yes

G.711a; G.711Mu; G.726; PCM

Network disconnection; IP conflict; illegal access; motion detection; audio detection; video tampering; security exception

Network

Network Port

RJ-45 (10/100 Base-T)

Network Protocol

IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; SMTP; FTP; DHCP; DNS; DDNS; NTP; Multicast; P2P

Interoperability

ONVIF (Profile S; Profile T); CGI

User/Host

6 (Total bandwidth: 24 M)

Edge Storage

FTP

Web Viewer

IE, Chrome, Firefox

Smart Phone

Cyber Security

IOS, Android

Configuration encryption; Trusted execution; Digest; Security logs; HTTPS; Trusted upgrade; WSSE; Trusted boot; Account lockout; Generation and importing of X.509 certification; Video encryption.

Power

Power Supply

12 VDC/PoE

Power Consumption

Basic: 1.2 W (12 VDC); 2.1 W (PoE) Max. (ICR switch + illuminator intensity): 2.8 W (12 VDC); 4 W (PoE)
